75 Ohm F Male Connector For LMR-400-75 Cable, Crimp/Non-Solder Contact

SKU EZ-400-FM-75-X-LC
QTY available Call us
Quantity Price
1 - 24 $17.84
25 - 49 $16.95
50 - 99 $16.06
100 + Call Us
Price $17.84

All Prices are in US Dollars and do not include duties



L-com's EZ-400-FM-75-X 75 Ohm type F Male Connector Crimp/Non-Solder Contact Attachment for LMR-400-75 and LMR-400-75-DB Cable is part of our full line of RF components available for same-day shipping. Our type F male connector operates up to a maximum frequency of 1 GHz and offers good VSWR of 1.3:1. Our 75 ohm type F male connector EZ-400-FM-75-X datasheet specifications and drawing with dimensions are shown below in this PDF. L-com’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and customize their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply create a custom cable assembly configuration, L-com has the right connector for the job. L-com can also expertly build your custom cable assemblies for you and ship same-day

Features
  • Operating Frequency of 1 GHz Max.
  • Good VSWR of 1.3:1
  • Gold Plated Beryllium Copper Contact
  • 50 µin contact platin

Application
  • General Purpose Test
  • Custom Cable Assemblies
  • CATV


Product Resources

Key Specifications

Key Specifications

Polarity
Standard
Connector Series
F
Connector Gender
Male
Impedance
75 Ohm
Attachment Method
Crimp/Non-Solder Contact
Mount Method
None
Minimum Frequency
DC
Maximum Frequency
1 GHz
Interface Type 1
LMR-400-75
Interface Type 2
LMR-400-75-DB
